Curtain PIR Detector
Model: HM-802C
The product is high stability curtain PIRdetector. It has adopted advanced technology in signal processing and provided superhigh detection ability and anti error alarm. The detector will detect movement of human automatically whenintruder passes through the detection area. The product is suitable for the safety of residential house, villas, factories, markets, warehouses, office building etc.
The product is high stability curtain PIRdetector. It has adopted advanced technology in signal processing and provided superhigh detection ability and anti error alarm. The detector will detect movement of human automatically when
intruder passes through the detection area. The product is suitable for the safety of residential house, villas, factories, markets, warehouses, office building etc.
●MCU control, anti false alarm efficiently
●Auto temperature compensation
●Pulse count adjustment
●Anti white light interference
●Anti RF interference (20V/m~1GHz)
●Fresnel lens
●Wall/ceiling installation
●Alarm output N.C./ N.O. Optional
Operating voltage: DC 9-24V
Alarm current:≤1 8mA(D.C.12V)
Detecting distance: wall mounted 9m; ceiling mounted 6m
Detecting angle: 15°
Self-testing time: about 60S
Radio distance: more than 100m (open area)
Alarm indicator: red LED
Alarm output: N.C./N.O. Optional, contact D.C.28V 100m
Anti-dismantle output: N.C., Contact D.C.28V 100mA
Sensor: dual element infrared sensor
Operating temperature:-10°C ~ +50C
Environment humidity:≤95% RH (no congelation)
Anti RF interference: 10MHz- 1GHz 20V/m
Installation mode: wall/ ceiling mounted
