IR Learner
Model: HDL-MIRL01.01
SB-IR-Learn.01 is the Infrared Code learner. It can learn various key commands. For example, you want to control the AC, TV, DVD, Audio & Video Device, etc. IR learner can be learned into HDL BUSPRO Pro system. It has the testing mode and it do not need the extra driver.
SB-IR-Learn.01 is the Infrared Code learner. It can learn various key commands. For example, you want to control the AC, TV, DVD, Audio & Video Device, etc. IR learner can be learned into HDL BUSPRO Pro system. It has the testing mode and it do not need the extra driver.
■ USB Interface, no driver and easy to use
■ Infrared Code learning
■ Infrared Code sending test
■ Indicator will flash when the device is learning the IR Code
■ Infrared Code learning
■ Infrared Code sending test
■ Indicator will flash when the device is learning the IR Code
Electrical Parameter：
Range of carrier wave frequency 38KHz±20%
USB 2.0, no need driver
Environmental Condition：
Working temperature -5℃~45℃
Working relative humidity Up to 90%
Storage temperature -20℃~+60℃
Storage relative humidity Up to 93%
Approved
CE
RoHS
Product Information:
Dimensions 98×70×38(mm)
Weight 179.7g
Housing material ABS
Installation USB 2.0 interface
Protection degree IP20
