Hotel Room Control Host
Model: MHC48IP.431
Hotel Room Control Host can be used in conjunction with the mix control module, other relay and dimming modules without scene controller, etc. The hotel room control host has 48 channels, which must be set through Hotel Room Management System. The hotel room host can monitor and control each equipment via Hotel Room Management System after setting up targets as doorbell panels, curtains, lamps, exhaust fan, air conditioners and other equipment.
Hotel Room Control Host can be used in conjunction with the mix control module, other relay and dimming modules without scene controller, etc. The hotel room control host has 48 channels, which must be set through Hotel Room Management System. The hotel room host can monitor and control each equipment via Hotel Room Management System after setting up targets as doorbell panels, curtains, lamps, exhaust fan, air conditioners and other equipment.
■ 48 channels control, each channel has parameter for lower limit, higher limit , the maximum limit.
■ There are 99 scenes in total, each scene’s running time is 0-250 seconds.
■ The protection delay time of each channel is 0-60 minutes.
■ The delay turn ON time of each channel is 0-250 Seconds.
■ It can run the scenes according to the identification of the card master.
■ Monitors and controls air conditioners, curtains, lightings, room status, and uploads the status of air conditioners, curtains, lightings and other states to the monitor software of the server in real time.
■ Receive various panel control signal, and control the module and channels.
■ Network connection. The hotel room control host has a RJ45 port, which can connect to each room, reception and management software. Through Hotel Room Management System, the module can integrate with the third party management software to exchange information.
■ Supports connecting to devices in RS485 communication.
Basic Parameters
Working voltage 12~30V DC
Working current 30mA/24V DC
RJ45 connection UDP/IP network interface
Buspro connector
HDL Buspro,
Inner Buspro
External Environment
Working temperature -5℃~45℃
Working relative humidity ≤90%
Storage temperature -20℃~60℃
Storage relative humidity ≤93%
Specifications
Dimensions 72mm×90mm×64mm
Net weight 143g
Housing material Nylon, PC
Installation
35mm DIN rail installation
Protection rating (Compliant with EN 60529) IP20
